Push Fittings (PushLock)

About Push Fittings (PushLock)

Push lock fittings, also known as push-to-connect fittings or quick-connect fittings, are a type of pipe fitting designed for easy and tool-free installation. These fittings allow for quick connections between pipes or tubing without the need for specialized tools, clamps, or adhesives. Push lock fittings are commonly used in plumbing, pneumatic, and hydraulic systems.

The main features and components of push lock fittings include:

1. Fitting Body: The fitting body is typically made of brass or plastic, depending on the application and the specific type of fitting. It is designed with a threaded or barbed end to facilitate connection with the pipe or tubing.

2. Collet: The collet is an internal component within the fitting body. It consists of several metal or plastic gripping teeth that secure the pipe or tubing in place when pushed into the fitting.

3. O-Ring or Seal: Push lock fittings often incorporate an O-ring or seal within the fitting body. This O-ring provides a watertight and leak-resistant connection when the pipe or tubing is inserted.

The installation process of push lock fittings is relatively simple and typically involves the following steps:

1. Preparation: The pipe or tubing end should be clean, deburred, and cut square to ensure a proper fit.

2. Insertion: The pipe or tubing is pushed into the fitting until it reaches a predetermined insertion depth. The collet teeth grip onto the pipe, ensuring a secure connection.

3. Testing: After installation, it is recommended to conduct a pressure test or leak test to ensure the integrity of the connection.

Advantages of push lock fittings include:

1. Ease of Installation: Push lock fittings offer fast and tool-free installation, reducing labor time and simplifying the connection process.

2. Versatility: Push lock fittings are available in various sizes and materials, allowing for compatibility with different pipe materials such as copper, PEX, PVC, and polyethylene tubing.

3. Removability: Push lock fittings can be easily disconnected and reused if needed, making them convenient for maintenance or system modifications.

4. Leak Resistance: When properly installed, push lock fittings provide a reliable and leak-resistant connection, minimizing the risk of fluid or gas leakage.

FEATURES & BENEFITS

• Shortens repair time on jobs.
• Lead Free removable brass fittings in sizes 1/2" to 1".
• Certified for potable water and hydronic applications.
• No Tools, No Heat, No Glue, No Flux and No Solder required.
• Connects PEX, CPVC, or COPPER pipe in any combination.
• Quick and easy, removable and reusable installation.
• Made with Lead Free DZR Forged Brass.
• Ideal for service and repair - even on wet lines.
• Pre-lubricated for quick installation.
• EPDM O-Ring for leak free seals.

SPECIFICATIONS & APPROVALS

• Certified to 200 PSI and 200°F
• Certified by UPC / IAPMO, to meet Lead-Free Potable Water Laws.
• ANSI/NSF-14/G Compliant
• AWWA C800 Compliant • Meets ASME B1.20.1, ASSE 1061
• Manufactured in an ISO Accredited Facility
